YC – 525 EL

YC – 525 EL

Pharmacy Refrigerator



Real Air Cooling:

The multi-duct vortex refrigeration system and finned evaporator can prevent frosting completely and improve temperature uniformity to a large extent



Real Energy Saving

The refrigerator is equipped with “M + Energy Core” power management system and complete air cooling design, improving energy saving efficiency by more than 40%



Real Visibility:

The electrical heating + LOW-E design with double considerations can achieve a better anti-condensation effect for the glass door



Real Safety:

Seven temperature probes can ensure high precision of temperature control with nearly no fluctuation and thus can improve safety



Intelligent Temperature Control

  • Equipped with high-precision microcomputer temperature control system and 1 high brightness digital temperature display with a display accuracy at 0,1° C.
  • Equipped with a remote alarm access port and 485 data access port.



Security System

  • The well-developed audible & visual alarm system with multiple audible &visual alarm functions: high temperature alarm, low temperature alarm, sensor failure alarm, door ajar alarm, power failure alarm etc.
  • The turn-on delay and stopping interval protection function can ensure reliability in running
  • The door is equipped with a lock, preventing it from opening accidentally



Refrigeration System

Equipped with a compressor supplied by an international famous brand, high-efficiency air-cooled condenser and finned evaporator, ensuring fast refrigeration.



Data Storage

  • Equipped with a USB export interface, which can be used for exporting data in PDF
  • When a U-disk is connected temperature data can be stored continuously and automatically (data can be stored for 100,000 sets of data)
  • The printer is optional.



Human-oriented

  • Equipped with high-quality shelves made from PVC-coated steel wire with tag cards and classification marks, which are easy to clean
  • Equipped with invisible door handle, ensuring elegance of appearance
  • Equipped with testing port, bringing convenience to users in testing temperature inside the cabinet



Scope of Application:

Suitable for storage of biological products, vaccines, drugs, reagents, etc. Suitable for use in pharmacies, pharmaceutical factories, hospitals, centers for disease prevention & control, clinics, etc.



  • Cabinet Type: Upright
  • Capacity (L): 525
  • Internal Size (W x D x H): 610 x 685 x 1264 mm
  • External Size (W x D x H): 720 x 810 x 1973 mm
  • Package Size (W x D x H): 775 x 868 x 2130 mm
  • Weight (N): 141 kg
  • Weight (G): 166 kg



Performance:

  • Temperature Range: 2 ~ 8ºC
  • Ambient Temperature: 16 ~ 32ºC
  • Cooling Performance: 5ºC
  • Climate Class: N
  • Controller: Microprocessor
  • Display: Digital Display



Refrigeration:

  • Compressor: 1 pc
  • Cooling Method: Air cooling
  • Defrost Mode: Automatic
  • Refrigerant: R 290
  • Insulation Thickness (mm): L / R: 55, B: 52



Construction:

  • External Material: Spray cold rolled steel plate
  • Inner Material: Aluminum plate with spraying (optional stainless steel)
  • Shelves: 6 (coated steel wired shelf)
  • Door Lock with key: Yes
  • Lighting: LED
  • Access Port: 1 pc. Ø 25 mm
  • Casters: 4 (2 caster with brake)
  • Data Logging: USB
  • Interval: Record every 10 minutes
  • Memory Capacity: 100.000 data
  • Door with heater: Yes



Alarm:

  • Temperature: High / Low temperature, High ambient temperature
  • Electrical: Power failure, low battery
  • System: Sensor failure, Door ajar, Built-in USB datalogger failure, Communication failure, Condenser overheating



Electrical:

  • Power Supply: 220 – 240 V, 50 Hz
  • Rated Power: 310 W
  • Power Consumption: 3,63 kWh / 24 h
  • Rated Current: 2,49 A



Accessories:

  • Standard: RS 485, Remote alarm contact, Backup battery
