YCD – EL 300

YCD – EL 300

Combined Refrigerator and Freezer


Environmentally Friendly & High-efficiency
Environmentally-friendly Freon-free refrigerant and high-efficiency compressor supplied by an international famous brand ensure energy saving and high efficiency.


  • Refrigeration System
    Two compressors and separate control of the upper refrigeration chamber and the lower freezing chamber.
  • High-precision Computerized Temperature Control
    The digital temperature display can indicate operating status clearly, and users may set the high temperature / low temperature alarm points based on their needs.


Thermal Insulation System
The CFC-free polyurethane foam technology and the thicker insulating layer can improve the effect of thermal insulation.


  • Temperature Control System:
    digital temperature display, clear opera- ion status, temperature points can be set according to High and low temperature alarm user requirements;
  • High precision microcomputer temperature control system, 2 ~ 8 °C refrigerated, Frozen - 10 ~ - 26 °C adjustable;
    Display both refrigerating temperature and freezing temperature, refrigerating room, The refrigerating chamber can be closed separately.


Refrigeration System:

  • Environmentally-friendly Freon-free refrigerant and high-efficiency compressor supplied by an international famous brand ensure energy saving and high efficiency.
  • Two compressors and separate control of the upper refrigeration chamber and the lower freezing chamber.
  • The CFC-free polyurethane foam technology and the thicker insulating layer can improve the effect of thermal insulation.


Security System:

  • The well-developed audible & visual alarm system makes it safer for storage;
  • The turn-on delay and stopping interval protection function can ensure reliability in running;
  • The door is equipped with a lock, improving security of sample storage.


Lighting System inside the Cabinet:
The LED lighting system provides great visibility.


Human-oriented:
Three steel wire shelf are standard in the refrigerator room, and three ABS drawers are standard in the freezer room;
Casters at the bottom with locking device for easy movement.


Scope of Application:
Suitable for freezing of ice bars and storage of various things needing refrigerated storage such as blood plasma, reagent, etc. Suitable for use in hospitals, clinics, health and disease prevention systems, blood banks, laboratories in colleges & universities, the frozen food industry and catering industry, etc.


  • Cabinet Type: Upright
  • Capacity (L): 300, R: 197, F: 103
  • Internal Size (W x D x H): R: 600 x 510 x 657 mm, F: 500 x 460 x 535 mm
  • External Size (W x D x H): 700 x 640 x 1876 mm
  • Package Size (W x D x H): 760 x 720 x 1935 mm
  • Weight (N): 95 kg
  • Weight (G): 106 kg



Performance:

  • Temperature Range: R: 2 ~ 8ºC, F: -10 ~ -26ºC
  • Ambient Temperature: 16 ~ 32
  • Cooling Performance: R: 5, F: -26
  • Climate Class: N
  • Controller: Microprocessor
  • Display: Digital display



Refrigeration:

  • Compressor: 2 pc
  • Cooling Method: R: Forced air cooling, F: Direct cooling
  • Defrost Mode: R: Automatic, F: Manual
  • Refrigerant: R 600 a
  • Insulation Thickness (mm): R: 50, F: 100



Construction:

  • External Material: PCM
  • Inner Material: Aluminum plate with spraying
  • Shelves: R: 3 (coated steel wired shelf), F: 3 (ABS)
  • Door Lock with key: Yes
  • Lighting: LED
  • Access Port: 2 pc. Ø 25 mm
  • Casters: 4 (2 casters with brake)



Alarm:

  • Temperature: High / Low temperature, High ambient temperature
  • Electrical: Power failure, low battery
  • System: Sensor failure, Door ajar, Built-in USB datalogger failure, Communication failure



Electrical:

  • Power Supply: 220-240 V, 50 Hz
  • Rated Power: 250 W
  • Power Consumption: 1,54 kWh / 24 h
  • Rated Current: 1,37 A
